Firewall Filter Types Layer 3

Firewall Filters Layer 3 Switch Security

Firewalls are a popular choice used in restricting network traffic at layer 3

Stateless Firewalls:

Statefull Firewalls

Firewall filter:Denying traffic from entering or exiting an interface

Firewall Filtreleme suralara uygulanabilir:

-Vlans

-Switch Ports

-RVIs

*EX series swirth firewall filters are stateless

Firewall filters uses Mac address table memory

Firewall Filter Types

Port Firewall Filter :

            Using for switch port .Filters match  Mac adres, and IPv4 ve IPv6  filtreleme

            Can applied as ingress

For example :If you apply for ge-0/0/1 interface , it will only effect
ge-0/0/1 interface on switch , it

Vlan Firewall Filter :

               Can applied against the 2 VLAN

                Filters are matched against layer 2 and layer 3

                Filters match against IPv4 and IPv6 and MAC Address

                Filters applied as egress





Router Firewall Filters

                 Can applied against RVIs and routed ports

                  Filters are matched against Layer 3

                   Filters match IPv4 and IPv6 addresses

                   Filters may be applied interface Lo0

                   Filters applied as egress

Also Mac address filters can apply IPv4 ve IPv6  f

Proccesing Order

Firewall Filters components:

Filter group

Only a single firewall filter may be applied to switch port, VLAN or RVI

A filter group can have up to 1024 terms

Terms

Criteria to match against are set using the “from” clause

“from” clause can match IP Addresses, TCP/UDP ports and Protocols

Once traffic matches a term the “then” statement

Implicit deny

*****If no terms are matched a packet is automatically dropped

Match Criteria and Actions

Matches are set using  a “from” statement

There are many criteria can be used with the from statement (Ip address, ports.Mac Address and Vlans)

Match Criteria-Destination

Destination IP address

Destination Mac address

Destination Port

Destinstion prefix-list

Match Criteria-Source

Source Ip adress

Source Mac address

Source port

Source prefix-list

Match Criteria-Layer 2

Dot1q tag

Ether type

Vlans

Match Criteria-QoS

Priority traffic could VOIP or video conferencing

Match Criteria-Ingress Only

Tcp Flags

Tcp initial

Fragment flags

Firewall Actions

Accept

Rejects

Discard (silenty denies the packet or frame)

 Action Modifiers

Count

Syslog

Log

Action Modifiers for -QoS

Forwarding Class

Loss Priorty
